Ritron Outpost call boxes plus GateGuard at great prices!

      PRODUCT INFORMATION
                        from
                   Falcon Wireless Direct

OutPost Wireless Callboxes and Gate Controllers

Falcon Wireless Direct offers a Family of Cost Effective Call boxes that are.......

ideally suited for campus security. The Series 6 Advanced Call box is our most popular model, priced at $995, for school campus use while the KP model, priced at $1,496 is best suited for access control.

All models are available in both the Basic and XT models which feature weather-resistant enclosures. The XT features a fiberglass enclosure with a stainless steel faceplate that includes tamper-resistant fasteners and a concealed antenna making it perfect to withstand any element.

1 Series Callbox
Basic Model: RQX-151/451
XT Model: RQX-151-XT/451-XT

6 Series Callbox
Basic Model: RQX-156/456
XT Model: RQX-156-XT/456-XT

7 Series Callbox
Basic Model: RQX-157/457
XT Model: RQX-157-XT/457-XT

"1" Series Features:

▫ Two-Way Communication

▫ Battery Powered or
Optional External Power

▫Wide or Narrow Band

▫Adjustable Power Output

All “1” Series Features Plus:

▫ Built-In Switch Relay for Remote Control Capability

▫ 2-Tone Decode

▫ DTMF ANI

▫ Sensor Input

All “1” & “6” Series Features Plus:

▫ Talking Callbox:
Programmable Voice Recording for Automatic Greeting

▫ Voice Locations Identification

For your convenience, we have listed detailed product information on each of our call boxes, and, we thought you would like to know - THEY ARE ALL MADE IN THE UNITED STATES OF AMERICA!

Model	Series 1	Series 6	Series 7	GateGuard	KP Model

Product Type	Basic Callbox	Advanced Callbox	Premium Callbox	Gate Controller	CallBox with Keypad
Product Application	Weatherproof 2-way call box is well suited for loading docks, secured doors and retail facilities	The more rugged Series 6 includes advanced control features for activation of external devices	Series 7 has custom programmable messages to assist caller and the recipient	Control gate opening and closing with either the Jobcom or Patriot 2-way radios. Solar power available	Keypad models allows all callbox features plus keypad access for control of locks & gates
User Price	$608	$995	$1,085	$1,495*	$1,496
Frequency Band	VHF or UHF	VHF or UHF	VHF or UHF	VHF or UHF	VHF or UHF
No. of Channels	1	1	1	1	1
Power source	6 "D" Cells	6 "D" Cells	6 "D" Cells	AC Power	AC Power
Operating life	7000 transmissions	7000 transmissions	7000 transmissions	Unlimited	Unlimited
Power upgrade	Solar Panel	Solar Panel	Solar Panel	Solar Panel	Solar Panel
Size	10.0 x 5.5 x 3.0"	9.7 x 11.5 x 4.3"	9.7 x 11.5 x 4.3"	9.7 x 11.5 x 4.3"	9.7 x 11.5 x 4.3"
Weight	1.63 pounds	7.32 pounds	7.32 pounds	7.32 pounds	7.32 pounds
Power Output	1 Watt	1 watt	1 watt	1 watt	1 watt
CTCSS & DCS	CTCSS only	Yes	Yes	Yes	Yes
2-tone Paging	No	Yes	Yes	Yes	Yes
DTMF ID	No	Yes	Yes	Yes	Yes
Relay control	No	Yes	Yes	Yes	Yes
Warranty	1 year Batteries excluded	1 year Batteries excluded	1 year Batteries excluded	1 year parts and labor	1 year parts and labor
Product brochure	www.ritron.com/ pdf/opt_04.pdf	www.ritron.com/ pdf/opt_04.pdf	www.ritron.com/ pdf/opt_04.pdf	www.ritron.com/ pdf/gg_07.pdf	www.info4u.us/ rqt.kp.pdf

*Includes one handheld radio and one fixed radio

Accessory Pricing

Mounting kit	Not applicable	$39	$39	$39	$39	Not applicable
Solar Power kit	$795	$795	$795	$795	$795	$795
AC Power supply w/UPS	$129	$129	$129	P/S Included	P/S Included	P/S Included
Blue strobe light	$350	$350	$350	$350	$350	Not applicable
PC Program kit	$125	$125	$125	$125	$125	$125
Carrying case	Not applicable	Not applicable	Not applicable	Not applicable	Not applicable	Not applicable
Spare battery	Not applicable	Not applicable	Not applicable	Not applicable	Not applicable	Not applicable
Stubby antenna	Not applicable	Not applicable	Not applicable	Not applicable	Not applicable	Not applicable
Spare clip	Not applicable	Not applicable	Not applicable	Not applicable	Not applicable	Not applicable
Speaker-Mic	Not applicable	Not applicable	Not applicable	Not applicable	Not applicable	$19
TotalCare 3 year service plan	$190	$190	$190	$380	$380	$95

User information. Products sold by Falcon Direct are warranted to be technically compliant with the manufacturers specifications. No other warranty relative to use of the equipment or related service, when applicable, is expressed or implied. Falcon Direct makes no claim for suitability or fitness of users purpose or application. Falcon Direct is not responsible for claims arising from the use of equipment or services provided by or through Falcon Direct in which there are losses attributed to the use or application of equipment and/or related services. User agrees to these terms as a condition of purchase.

Extended Care Programs

In addition to the normal warranty, Falcon Direct offers a variety of special service programs to meet the special needs of those we serve. TotalCare offers three years of service with next day exchange replacement, all shipping cost and repairs for just $95 on all Ritron radios excluding call boxes and repeaters. TotalCare service on call boxes or repeaters is $190 for three years of service. Optionally, flat rate repair is available that provides all repairs, upgrades, housings, clips, batteries, and return shipping cost for a single flat rate fee. The cost of repair on all Ritron radios with the exception of repeaters and call boxes is $95. The cost of flat rate repair on call boxes or repeaters is $265. Abuse and damage caused by water or lightning is excluded. Call us at 1.800.489.2611 for more information.

FCC Licensing

All 2-way radios used for business and governmental use must be licensed excluding low powered Family Radio Service (FRS) radios - period, no exceptions, ever, for anybody except one. The MURS (Multi Use Radio Service) is available for anyone to use - business, personal or public safety. Five frequencies are available in the VHF 150 - 154 MHz band for fixed station, mobile, handheld or call box use. General Mobile Radio Service (GMRS) frequencies are NOT approved for commercial or governmental use. The so called color dot frequencies DO require an FCC license for use. All licensed base stations (Stationary Radio Units) must transmit their assigned station call letters in voice or Morse code at least once every hour (with the exception of MURS operation). Substantial fines can result from improper operation. Falcon Direct can assist you in obtaining an FCC license. An optional accessory is available for Patriot fixed station equipment that will provide automatic station identification for licensed systems. Call us at 1.800.489.2611 for additional information.
